  Home > Integrated Motors >

AMC China: Golden Ding Series 100W,CANopen,Integrated Motor with Brake,JDC-010BIP65
100W,CANopen,IP65,Integrated Servo Motor

Price : $1,250.00

Price with Selected Options: $1,250.00


Availability: Back Order
Order #: JDC-010BIP65


Accessories:

Qty:
Description Ordering Information Specifications and Drawings

AMC China Integrated Servo Motor
Golden Ding Series Integrated Motor build-in DC brushless motor with brake or without brake, encoder, servo drive, and controller in one package. We provide 2 series basic on communication CANopen and RS485,
5 power products of 100w,200w,400w,600w, and 750w for 2 kinds of IP20 and IP65, and 2 ranges temperature -25-75℃ and -40-65℃.

Golden Ding Series Integrated Motor Application
-Assembly automation: AGV, RGV, robot, tooling equipment;
-Measurement automation: The measurement of parts is in the fields of automobiles, airplanes, 3C, etc.;
-Testing equipment: ultrasonic flaw detection, airport security inspection;
-Semiconductor equipment: wafer transfer and pick and place;
-Communication field: signal conditioning, mobile antenna positioning;
-Medical field: CT scanner, blood analyzer, biochemical analyzer, X-ray machine;
-Intelligent equipment: airborne, shipborne, and vehicle-mounted automation equipment;
-laboratory automation;
-General automation

Golden Ding Line Series Integrated Motor Specification


Golden Ding Line Series Integrated Motor Model and Data List

Rated

Power

W

Rated

Torque

Nm

Rated Speed

@48VDC input

RPM

Flange

Size

mm

Power Supply Range

20-80VDC,with Hall and 4096 incremental magnet encoder

Shaft

Operation Temperature

-25-75℃

-40-65℃

IP Level

IP20

IP65

IP20

IP65

Without STO

With STO

CANopen

100

0.32

3000

40

Without Brake

JDC-010N

JDC-S010N

JDC-010NIP65

JDCX-010N

JDCX-010NIP65

Round

With Brake

JDC-010B

JDC-S010B

JDC-010BIP65

JDCX-010B

JDCX-010BIP65

200

0.64

60

Without Brake

JDC-020N

JDC-S020N

JDC-020NIP65

JDCX-020N

JDCX-020NIP65

With Key

With Brake

JDC-020B

JDC-S020B

JDC-020BIP65

JDCX-020B

JDCX-020BIP65

400

1.30

60

Without Brake

JDC-040N

JDC-S040N

JDC-040NIP65

JDCX-040N

JDCX-040NIP65

With Brake

JDC-040B

JDC-S040B

JDC-040BIP65

JDCX-040B

JDCX-040BIP65

600

1.90

80

Without Brake

JDC-060N

JDC-S060N

JDC-060NIP65

JDCX-060N

JDCX-060NIP65

With Brake

JDC-060B

JDC-S060B

JDC-060BIP65

JDCX-060B

JDCX-060BIP65

750

2.40

80

Without Brake

JDC-075N

JDC-S075N

JDC-075NIP65

JDCX-075N

JDCX-075NIP65

With Brake

JDC-075B

JDC-S075B

JDC-075BIP65

JDCX-075B

JDCX-075BIP65

RS485

100

0.32

40

Without Brake

JDR-010N

JDR-010NIP65

JDRX-010N

JDRX-010NIP65

Round

With Brake

JDR-010B

JDR-010BIP65

JDRX-010B

JDRX-010BIP65

200

0.64

60

Without Brake

JDR-020N

JDR-020NIP65

JDRX-020N

JDRX-020NIP65

With

With Brake

JDR-020B

JDR-020BIP65

JDRX-020B

JDRX-020BIP65

400

1.30

60

Without Brake

JDR-040N

JDR-040NIP65

JDRX-040N

JDRX-040NIP65

With Brake

JDR-040B

JDR-040BIP65

JDRX-040B

JDRX-040BIP65

600

1.90

80

Without Brake

JDR-060N

JDR-060NIP65

JDRX-060N

JDRX-060NIP65

With Brake

JDR-060B

JDR-060BIP65

JDRX-060B

JDRX-060BIP65

750

2.40

80

Without Brake

JDR-075N

JDR-075NIP65

JDRX-075N

JDRX-075NIP65

With Brake

JDR-075B

JDR-075BIP65

JDRX-075B

JDRX-075BIP65


IP20 Golden Ding Series Integrated MotorCables


IP65 Golden Ding Series Integrated MotorCables
