ATI: DAQ Interface Power Supply 9105-IFPS-1
Interface Power Supply Box
The Interface Power Supply (IFPS) box is used with the small Nano and Mini transducers. The IFPS Box supplies power to the transducer and supplementary electronics; it also conditions the transducer signals utilized by the data acquisition system. For the drawing, Power to the IFPS box can be provided through either the 12 V wall-mounted power supply included with the IFPS box; or a 5 V source from the DAQ device through the 26-Pin male connector located on the box. The IFPS box only requires one source; if both sources are connected, the IFPS box will use the 12 V source and the 5 V source will be ignored.
