CODESYS OPC UA Server SL Article no. 2302000041
The OPC UA Server exposes variables configured in the symbolic configuration of a CODESYS project to the OPC UA address space. Clients can read, write and monitor the values of the PLC. To enable the OPC UA support in the CODESYS Development System the option “Support OPC UA Features” must be set in the symbol configuration.

Also see [CODESYS Online Help](https://help.codesys.com/webapp/_cds_runtime_opc_ua_server;product=codesys).

The OPC UA Server supports the following features:

Browsing of data types and variables

Standard read/write services

Notification for value changes (subscription and monitored item services)

No restriction in the number of sessions, monitored items, and subscriptions (the number depends on the performance of the respective platform)

Support of events

Support of complete access to structures

Encrypted communication with an OPC UA Client

Support of multitasking

Support of OPC UA methods

Support of Alarms&Conditons

Supported profiles: Currently the OPC UA server supports the “Micro Embedded Device Server Profile”. This server profile allows reading, writing, and subscribing of items.

Supported information models: OPC UA allows defining different data types. The combination of customer defined data types, object types and reference types allows defining your own information model. An information model describes how the data should be exposed to the address space.

PLCopen information model

User-defined information models (companion specifications)

Also see [CODESYS Online Help](https://help.codesys.com/webapp/_cds_using_opc_ua_information_models;product=codesys).

Security: * X.509 based communication * User management

SecurityProfiles: - None - Basic256Sha256 (Sign, Sign_and_Encrypt) - Aes128_Sha256_RsaOaep - Aes256_Sha256_RsaPss

User token policy: - Anonymouse - Username
