Brushless DC-Gearmotors: Series 1515...B

(Diameter: 15 mm, Length: 15.2 mm)

Brushless DC-Motors

Whether it's high torque 4 pole servomotors, highly efficient flat motors,or compact slotless motors, FAULHABER specializes in getting the most performance out of the smallest package.

Due to their design FAULHABER brushless motors are ideal for heavy duty servo applications with frequent overload conditions as well as for continuous duty applications where maximum operational lifetime is required.

Brushless DC-Gearmotors

The innovative FAULHABER BLDC Gearmotors are also available with an extremely compact integrated spur gearhead for speed reduction and a significant increase in the available output torque.

There are a wide variety of reduction ratios available in the same compact housing design.

Features and Benefits:

Model No.: 1515U006B 112:1, 1515U006B 13:1, 1515U006B 324:1, 1515U006B 39:1, 1515U006B 6:1, 1515U012B 112:1, 1515U012B 13:1, 1515U012B 324:1, 1515U012B 39:1, 1515U012B 6:1
