Heidenhain: AE LC 291F Scanning Unit for Absolute Sealed LC 200 Linear Encoder

AE LC 291F

(ID: 828203-01)
AE LC 291F Scanning unit for absolute sealed LC 200 linear encoder

Grating period: 40.000 µm

Measuring step 1: 12.5000 nm

Measuring step 2: 50.0000 nm

Data interface: Fanuc05 Serial interface

FANUC ALPHA/ALPHAi

Power supply: 3.6 V ... 14 V

Electrical connection: Flange socket, male,

14-pin
