Mitsubishi Servo Drive Unit-MR-J2-60D-S2

MITSUBISHI MR-J2-60D-S2 The characteristics of this servo drive MITSUBISHI MR-J2-60D-S2 belonging to the MR-J2-60D-S2 Series Meldas are the following:

Input: 3.2A 3PH 200-230V 50/60Hz

0.3A 1PH 200-230V 50/60Hz

Output: 3.6A 3PH 170V 0-360Hz

Power: 0.6kW

This MITSUBISHI MR-J2-60D-S2 servo drive unit can drive motors from MITSUBISHI HC-* series with power of 0.6kW. This MITSUBISHI MR-J2-60D-S2 axis drive ready to replace your defective or faulty drive is refurbished, tested an accompanied with a functional warranty.

The MITSUBISHI servomotor's absolute value can be maintained by installing the MITSUBISHI A6BAT MR-BAT battery in the servo amp. There is no need to install the battery when using the servomotor in incremental mode. MITSUBISHI MELDAS MR-J2-60D-S2
