MITSUBISHI MDS-C1-SPH-300 CNC Spindle drive unit.

Features of the MDS-C1-SP spindle system.

(1) The converter that was conventionally built into the spindle controller has been installed in the unit (MDS-C1-SP), and can be used commonly with the other axis drive units. This allows great reductions in size and weight.

(2) The speed response has been improved by using a high-speed CPU, and the cutting performance and cutting precision during positioning control has been improved.

(3) A high-speed orientation method that allows direct orientation from high-speeds has been incorporated allowing smooth operations and minimum orientation times.

(4) All spindle parameters can be set from the NC CRT screen thus enhancing the operability.
