ELMO MOTION CONTROL - Multi-Axis Motion Controllers for Harsh Environment-Platinum Lion

The Platinum-Lion (P-Lion),Elmo’s ExtrIQ version of the Platinum-Maestro is the world’s most advanced and ruggedized multi axis network motion controller, suitable for operation in any environment.

Based on the world’s most advanced motion controller – the Platinum Maestro, incorporating an integral high level computational dual-core system (2 x 1.5 GHz) with memory and onboard additional hardware peripherals, the P-Lion surges the boundaries of any machine, optimizing overall accuracy, speed, and throughput of any system.

Its extended connectivity makes the P-Lion ideal for applications such as Inertial Platform Stabilization, requiring high speed, high responsiveness IMU/gyro support.

With countless multi-axis motion algorithms and features such as 3D high resolution error mapping, high-order polynomial motion segments and trajectory buildup, smart gearing, dynamics PVT and more, the P-Lion is the ultimate controller for extreme, precise, and reliable motion.

Platinum Lion Highlights:

Self-sufficient machine motion control – No reliance on connection with PC server

Multiple communication options: EtherCAT, CANopen, High Speed USB, Ethernet, RS-232
Fast EtherCAT networking controller with minimal cycling time of 100µs (for 8 synchronized axes), and cycle jitter below 5µs resulting in a precise, reliable and deterministic motion

Rich I/O connectivity. Time deterministic control over motion, I/Os and processes in the system, allowing direct controller level support for digital and analog I/O, accelerometers, encoders, serial interfaces, and IMUs

Full, real-time, multi-axis motion synchronization

Low-level communication with drives and I/O devices over the device network uses the CAN industry standard (DS 301, DS 401 for I/O devices, and DS 402 for drives and motion device profiles), and the new EtherCAT CoE (CAN over EtherCAT) protocols

Advanced user programming capabilities based on the leading standards. Provides full flexibility for either IEC 61131-3 or C/C++ programming

Unified development platform that streamlines motion control solutions for novice and expert programmers alike

Complete compatibility with recognized networking and communications protocols

Supports a wide variety of feedback sensors

Shares the motion processing workload with Elmo’s SimplIQ and Gold Line drives, forming a distributed motion control system
