The OEM-AT6400 does not have the I/O optical isolation circuitry that is standard for most of

the 6000 Series indexers/controllers. Special care must be taken to minimize electrical noise

in the immediate environment to ensure proper operation of the OEM-AT6400. The

guidelines listed below should help you minimize the potential for electrical noise.

• Do not route high-voltage wires and low-level signals in the same conduit, noise

considerations.

• Ensure that all components are properly grounded.

• Ensure that all wiring is properly shielded
