Thomson: DuraTRUE™ Planetary Gearheads (DT115 Series)

Thomson Micron® planetary gearheads are used on high precision motion control applications which require a high torque to volume ratio, high torsional stiffness, and low backlash. All of our gearheads are self-lubricating and have high radial load capacity for any given size. The ability to match inertias with our large variety of ratios, provide to keep our customers stable and controlled servo systems.

DuraTRUE™ Planetary Gearheads

Description

The DuraTRUE™ is a high precision, True Planetary gearhead that utilizes the Thomson Micron® RediMount system. With a variety of shaft configurations, you can design your system in the smallest of envelopes eliminating the need for coupling. The “T” design allows the ability to run two axes with one motor. The DuraTRUE has many ratios in stock for immediate delivery through the Thomson Micron Gearhead Express program.

DuraTRUE™ Highlights

• High Torque to Size Ratio - allows compact design
• Low Backlash - eliminates positioning errors due to lost motion
• Inertia Matching - keeps servo system stable and in control
• High Rigidity - optimizes system response
• Self Re-lubrication - eliminates costly maintenance and downtime
• High Radial Load Capacity - mount pulleys and pinions directly on the output shaft
• Error Free Mounting - Redimount Compliant

Product Featur

• Precision: 8 arc-minutes
• Frame Sizes: 115 mm
• Torque Capacity: up to 284 Nm
• Ratio Availability: 3:1 thru 100:1

Model No.: DT115-003, DT115-004, DT115-005, DT115-007, DT115-010, DT115-015, DT115-020, DT115-025, DT115-030, DT115-040, DT115-050, DT115-070, DT115-100
