Thomson: XTRUE™ True Planetary Gearheads (XTA070 Series)

Thomson Micron® planetary gearheads are used on high precision motion control applications which require a high torque to volume ratio, high torsional stiffness, and low backlash. All of our gearheads are self-lubricating and have high radial load capacity for any given size. The ability to match inertias with our large variety of ratios, provide to keep our customers stable and controlled servo systems.

XTRUE™ True Planetary Gearheads

Description

The XTRUE Series is a new precision gearhead that complements our True Planetary™ Gearhead line, already the largest selection of planetary gearheads in the world.

Benefits

• Move a larger load more easily and quietly with True planetary gearing through improved load capacity, lower backlash and quieter operation.

• Experience less downtime with the flexible mounting system: RediMount™ system mounts to any motor in 3 easy steps; align, mount and tighten.

• Simplify replacement with the tapped face output which enables easy drop-in replacement.

• Go green on your machine when the assembly and all components meet EU Directive 2002/95/ EC (RoHS)

Features

• Frame sizes : 70mm

• Precision: 13 arc-minutes

• Torque capacity: up to 55 Nm

• Ratio availability: 3:1 thru 100:1

Model No.: XTA070-003, XTA070-004, XTA070-005, XTA070-007, XTA070-010, XTA070-015, XTA070-020, XTA070-025, XTA070-030, XTA070-040, XTA070-050, XTA070-070, XTA070-100
