Yaskawa: Servomotor SGMSH-40ACA61
Yaskawa: Servomotor SGMSH-40ACA61

Alternate View

Price : $1,950.00


Availability: Usually Ships in 2 to 3 Weeks
Order #: SGMSH-40ACA61
Qty:

Description Ordering Information Specifications and Drawings


Yaskawa: Servomotor SGMSH-40ACA61

1.0kW to 5.0kW, Rated Speed 3,000 RPM

The SGMSH Sigma II servo motor is a legacy product and no longer promoted in the Americas. The SGMSH servo motor series had a high torque-to-inertia ratio and incorporated the segmented stator design, which dramatically reduced overall size. These servo motors were well suited for high-cycle-rate applications.

Features:

  • Time Rating: Continuous

  • Insulation: Class F

  • Vibration: 15mm or less

  • Withstand Voltage: 1500VAC

  • Insulation Resistance: 10MW minimum at 500VDC

  • Enclosure: Totally-enclosed, self-cooled IP67 (except for shaft opening)

  • Ambient Temperature: 0 to 40ºC

  • Ambient Humidity: 20 to 80% (non-condensing)

  • Rated Speed: 3000rpm

  • Maximum Speed: 5000rpm

  • Excitation: Permanent magnet

  • Drive Method: Direct drive

  • Mounting: Flange-mounted

  • Painting Color: Munsell notation N1.5
