Crouzet: Manually Operated Switches (83540/83542/83543/83547 Series) Pushbuttons
Crouzet: Manually Operated Switches (83540/83542/83543/83547 Series) Pushbuttons

Call for Pricing

Price Quote Form


Order #: 8354X


Model Number/Code*:

.
Description Specifications and Drawings


Crouzet: Manually Operated Switches (83540/83542/83543/83547 Series) Pushbuttons

Specifications

  • Approx body size (mm): min 22x19x10

  • Type: Subminiature

  • Action: Momentary+Maintained

  • Number of poles: 1 → 4

  • Rating (max): 6A / 250Vac

  • Degree of protection: IP40/IP50

  • Operating temperature: -20°C / + 125°C

  • Mechanical life (cycles): 0.5 M

  • Connections: Fast-on Solder Printed board
