Beckhoff: Industrial PC (CP77xx Series)

The compact Industrial PC with mounting arm

The CP77xx Panel PC series is designed for mounting arm installation. Control Panels form the front of the IP 65 Panel PC. The right display size and keyboard are thus available for every application. The CP77xx Industrial PCs represent a powerful platform for use in machine and plant construction, for example using the TwinCAT automation software.

The PC can be equipped with a 12-, 15- or 19-inch LC display, as a monitor without keys or with different types of keyboard. Optionally, a touch screen or touch pad is available. In addition, a large number of push-button extensions are available.

Cooling is achieved directly via the rear panel of the Control Panel. No fan is required. The PC can be operated at up to 45 °C ambient temperature.

The housing is optionally designed for direct wall mounting or for mounting arm installation. The mounting arm can be attached from above or below. If a mounting arm is used, the connection cables are fed through the mounting arm adapter attached centrally at the rear. Prefabricated cables in various lengths are available for the Ethernet connections.

The compact aluminum housing of the Panel PCs CP77xx is equipped with a Beckhoff motherboard for Intel® Celeron® ULV.

Due to its two independent gigabit Ethernet interfaces, the CP77xx are ideally suited as a compact central processing unit for an EtherCAT control system.

The CP77xx series Panel PCs are supplied with a 24 V power supply unit. The CFast card and the lithium battery for the system clock are located under a cover and accessible from the rear.

Model No.: CP7701-0000-0030, CP7701-0000-0040, CP7701-0001-0030, CP7701-0001-0040, CP7701-0020-0030, CP7701-0020-0040, CP7701-0021-0030, CP7701-0021-0040, CP7702-0000-0030, CP7702-0000-0040, CP7702-0001-0030, CP7702-0001-0040, CP7702-0020-0030, CP7702-0020-0040, CP7702-0021-0030, CP7702-0021-0040, CP7703-0000-0030, CP7703-0000-0040, CP7703-0001-0030, CP7703-0001-0040, CP7703-0020-0030, CP7703-0020-0040, CP7703-0021-0030, CP7703-0021-0040, CP7709-0000-0030, CP7709-0001-0030, CP7711-0000-0030, CP7711-0000-0040, CP7711-0001-0030, CP7711-0001-0040, CP7712-0000-0030, CP7712-0000-0040, CP7712-0001-0030, CP7712-0001-0040, CP7713-0000-0030, CP7713-0000-0040, CP7713-0001-0030, CP7713-0001-0040, CP7719-0000-0030, CP7719-0001-0030, CP7721-0000-0030, CP7721-0000-0040, CP7721-0001-0030, CP7721-0001-0040, CP7721-0002-0030, CP7721-0002-0040, CP7722-0000-0030, CP7722-0000-0040, CP7722-0001-0030, CP7722-0001-0040, CP7722-0002-0030, CP7722-0002-0040, CP7723-0000-0030, CP7723-0000-0040, CP7723-0001-0030, CP7723-0001-0040, CP7723-0002-0030, CP7723-0002-0040, CP7729-0000-0030, CP7729-0001-0030, CP7731-0000-0030, CP7731-0000-0040, CP7731-0001-0030, CP7731-0001-0040, CP7731-0002-0030, CP7731-0002-0040, CP7732-0000-0030, CP7732-0000-0040, CP7732-0001-0030, CP7732-0001-0040, CP7732-0002-0030, CP7732-0002-0040, CP7733-0000-0030, CP7733-0000-0040, CP7733-0001-0030, CP7733-0001-0040, CP7733-0002-0030, CP7733-0002-0040
