Semiconductor manufacturing equipment

General industrial machinery

Food machinery

Medical devices

Low vibration: This driver features approximately 30% less vibration compared with our conventional product.*1

High Torque: Increased by approximately 5%*1 when combined with our newly developed motors.*2 As output torque is the same for both 100 and 200 VAC input voltages, there is no need to change motors if power specifications change.

Analysis function and device startup support: Using an encoder with the motor makes it possible to monitor information such as the current position and speed. It simplifies determining causes of vibration and step-out.

Brake Control: Equipped with power supply for electromagnetic braking to automatically control open/close timing. No external power is needed for braking.

Rich Resolution Selection: It is equipped with 1/1 to 1/250 micro-step and electronic gear functions. Motor resolution can be set by ball screw pitch and reduction gear ratio.

Compact size: This driver features a 29% reduction in volume compared with our conventional product.*1
