Panasonic: Modular High-Speed PLC (FP2SH Series)

Panasonic PLCs offer an outstanding price-performance benefit which incorporates numerous functions including PID, adaptive filters, electronic cam control, multi-axis interpolation and more, all in a very compact body. Panasonic PLCs undergo extremely rigorous testing during development that far exceeds the demands that will actually be placed on them. This is a guarantee for the long life of the product in end-use applications. Panasonic's PLC programming software, Control FPWIN Pro, was one of the first on the market conforming to the international standard IEC 61131-3. In addition to all of this, Panasonic employs highly trained application engineers that can assist in providing custom designed systems.

Specifications:

• A high-performance model for high-speed operation
  Scanning time of 1ms for 20k steps. With an operating speed at the top of its class, super high-speed processing is made possible. The result is a dramatically decreased tact time and high-speed device.

• Large programming capacity of up to 120k steps
  Large programming capacities of 60k and 120k are available, depending on the model.

• Combine modules like building blocks
  I/O units, intelligent units, power supply units and backplanes can be used together for the FP2 and the FP2SH. I/O units can be located anywhere on the backplane.

• Optional small PC card is also available
  The small PC card is available for programming backup or data memory expansion. This allows you to process great amounts of data.

• Built-in comment and real-time clock functions
  These functions, optional with the FP2, are built right into the FP2SH.
