Panasonic: PLC (FP7 Series)

Panasonic PLCs offer an outstanding price-performance benefit which incorporates numerous functions including PID, adaptive filters, electronic cam control, multi-axis interpolation and more, all in a very compact body. Panasonic PLCs undergo extremely rigorous testing during development that far exceeds the demands that will actually be placed on them. This is a guarantee for the long life of the product in end-use applications. Panasonic's PLC programming software, Control FPWIN Pro, was one of the first on the market conforming to the international standard IEC 61131-3. In addition to all of this, Panasonic employs highly trained application engineers that can assist in providing custom designed systems.


FP7 "Seven steps to Higher Efficiency"

  • Compact size with room for expansion functions.

  • Equipped with a cassette interface.

  • Add-on cassettes can be added to the CPU to increase functionality without increasing the footprint of the system.

  • Up to 16 different units can be connected to a single CPU.

  • High-capacity SD (SDHC) memory cards of up to 32GB are supported.

  • High performance (max. 20μs for 60k steps); the processing speed is less affected by frequent Ethernet communication.


FP7 CPU

  • Equipped with a large memory capacity (up to 220k program steps or up to 500k data words) and a high-speed processor (11ns/step).

  • Local & remote connectivity: The standard CPU boards with Ethernet interface offer connectivity without limits, from remote programming to monitoring and data logging to FTP server and Modbus TCP.

  • Security & reliability: Built-in program backup. Production can resume in the event of fault. Original program is immediately to hand.

  • Traceability: Operational and program editing events are logged. Automatic logs of program download and upload are useful, especially for program debugging.

  • Maintenance: Hour meter operation - The built-in clock/calendar function can be adjusted via Ethernet.
