Main Body, Peripheral Components

Nominal (Height): 45

Precision: High Grade / Precision Grade

Table: Long 1 pc. / Long 2 pcs. / Short 1 pc. / Short 2 pcs

Lead(mm): 10～20

Motor Mounting Orientation: Straight

Cover: Not Provided / Included

Grease: Standard / Low Particle Generation

With or w/o Motors: Not Provided (Installed by customers)

With or w/o Lubricant Unit: Not Provided

Ball Screw Shaft Dia.(φ): 15

Table Length L1(mm): 43.5～81

Table Width W1(mm): 59.5～104
