MicroE: Optical Linear Encoders (Mercury™ Series)

Nano | Miniature Precision Encoders for the World’s Smallest Spaces

MicroE’s renowned PCB-mounted Mercury™ Encoders deliver up to 78nm resolution in an extremely compact and light package (5.6mm installed height, 2g weight), enabling machine and instrument designers to achieve rapid accelerations and high throughput in applications where size and mass are critical.

Benefits

  • Miniature PCB mount sensor provides significant space and cost savings through design integration

  • Wide alignment tolerance make for easy installation and setup

  • Analog outputs can be interpolated by the customer’s electronics for resolution up to 78nm

  • Low power consumption aids in thermal stability of the system

Model: M1200

Resolutions from 5µm to 78nm, 1Vpp analog interface with index, accuracy to +/-1 µm/m, small PCB mount sensor.

Model: M1500P

Resolutions from 5µm to 0.5µm, A-quad-B digital interface with index, accuracy to +/-1 µm/m, small PCB mount sensor.
