Extruded aluminum actuator body with T-slots for ease of mounting

Easy to adjust belt tensioner

One piece, machined and stress proof shafted pulley

Zero backlash belt to pulley design

Corrosion resistant components

Maximum Load: 90.72 kg (Horizontal), 45.36 kg (Vertical)

Maximum Speed: 10160 mm/sec (Horizontal), 5080 mm/sec (Vertical)

Repeatability: +/- 0.025 mm

Moment Load: 26 Nm

Acceleration Exceeding: 9 G's

Beam Dimensions: 80 x 80 mm

Weight: 17.24 kg (First meter of travel), 8.85 kg (Additional per meter)

Standard Stroke: 311 to 5811 mm (50mm Pitch)

Standard Length: 750 to 6250 mm (50mm Pitch)

Weight of Drive Pulley: 263.9 g

Weight of Idler Pulley: 179.8 g

Weight of Cart: 3.54 Kg

Weight of Belt: Stroke(mm) x 0.28 + 20.75 g

Travel per Revolution: 150 mm

Pulley Pitch Diameter: 47.74 mm

Pulley Material/Width: Steel / 25 mm

Breakaway Torque: 30 - 31 N-cm

Rolling Resistance: 8.2 g
