Isolated Outputs and Grounds

Withstands 300VAC Surge Input for 5 Seconds

Protections: Short circuit / Overload / Over voltage

Cooling by free air convection

LED indicator for power on

All using 105°C long life electrolytic capacitors

Output #2: 24 VDC @ 4.6 Amps, 120mV pk-pk

Output #1: 5 VDC @ 4.6 Amps 80mV pk-pk
