OPTION: 5VSB and Enable function with RPSG Models

Output(s): CH1: 5.0V @ 12.00A, CH2: 24.0V @ 3.60

Power (Convection): 100.2 Watts

Power (20.5 CFM): 150.4 Watts

Voltage Adj. Range: CH1: 5~ 5.5V

Dimensions (Inches): 5.00” x 3.00” x 1.36"

Operational Efficiency: 84.00%

Operating Temperature: -20 ~ +70°C

Medical Safety Approvals (UL/EN60601)

Universal AC input / Full range with Active PFC

Short circuit / Overload / Over voltage Protection Circuits

High Density 3 x 5 Package

Free air convection for 110W and 160W with 20.5 CFM forced air

<0.75W No-Load Power Consumption with optional PS-ON control

Power Good / Fail Signal

Remote Sense on Single 5-15V Models only

3 year warranty

Weight: 0.33 Kg
