Moog: Aerospace / Military Resolvers

Highly Accurate Brushless Resolvers

Moog brushless resolvers are economical and highly accurate. Motion feedback sensors can be used to provide velocity and position information for closed-loop electronic control, as well as brushless DC motor commutation. They contain no internal electronics or optics and are unaffected by electrical noise, heat, shock and vibration. We manufacture quality motion technology products for aerospace, military and commercial applications.

Rugged, reliable - ideal for demanding environments

Resolvers provide accurate position and velocity feedback as well as commutation in precision equipment, without the structural or temperature restrictions imposed by other electronic feedback devices. They are resistant to the shock and vibration levels often encountered in military and aerospace applications.

These resolvers are available in standard sizes, or with custom modifications. Our engineering department is available for consultation to help tailor a resolver to fit your needs.

Features

Integration Capabilities

Typical Applications (Where precise position indication is required to interface with resolver to digital converters):

Model No.: SGH-78-B-2, SGH-78-C-2, SGH-78-D-2, SMH-12-A-1, SMH-14-A-1, SMH-16-J-1, SMH-17-B-3, SMH-30-B-1, SMH-30-C-1, SMH-30-E-1, SMH-32-D-1, SMH-34-C-1, SMH-34-G-1, SMH-37-A-3, SMH-37-J-1, SMH-43-E-1, SMH-53-A-1, SMVH-44-A-2, SSBH-40-C-1, SSH-12-A-2, SSH-12-D-2, SSH-23-S-1, SSH-50-B-1, SSJH-36-B-3/P195, SSJH-36-K-1, SSJH-37-J-4, SSJH-43-C-1, SSJH-46-C-1, SSJH-50-B-3, SSJH-60-A-1, SSJH-60-D-1, SSJH-63-A-1, SSJH-98-A-1
