Heidenhain: CNC Controls (TNC 320 Series)
Heidenhain: CNC Controls (TNC 320 Series)

Call for Pricing

Price Quote Form


Order #: TNC-320
.

Description Specifications and Drawings


Heidenhain: CNC Controls (TNC 320 Series)

Controlling Machine Tools


For milling machines, milling/turning machines and machining centers:

  • Form a complete product line with their various features

  • Control machines with up to 18 axes

  • Their Klartext conversational programming capability is suited for the workshop floor

  • Can also be programmed externally

  • Are also suited for automated production

  • Are the correct choice for everything from simple milling procedures to high-speed milling


The contouring control for lathes:

  • Ideal for both CNC and cycle lathes

  • Enables the familiar manual production of simple workpieces

  • Supports programming with many cycles

  • Its smart.Turn feature offers form- and graphics-supported programming for complicated workpieces

  • Performs complementary milling and drilling operations in a single fixture

  • Also supports vertical lathes

  • Suited for digital or analog drive control


TNC 320 - The Compact Contouring Control for Milling, Drilling and Boring Machines

Thanks to its flexible operating concept – workshop-oriented programmability with HEIDENHAIN conversational programming or external programming – and its scope of features, it is especially suited for use on universal milling, drilling and boring machines for:

  • series and single-part production

  • tool and die making

  • manufacture of machines

  • research and development

  • prototype production and testing facilities

  • repair departments

  • educational and training institutes


The TFT 15-inch color monitor shows a clear overview of all relevant information for programming, operating and inspecting the machine tool and control such as program blocks, comments and error messages. More information is provided through graphic support during program entry, test run and actual machining.

The selectable split-screen display shows the part program blocks in one half of the screen and the graphics or the status display in the other half.

During the course of the program, status displays will always offer information on tool position, the current program, active cycles and coordinate transformations, and other data. The TNC 320 even shows the current machining time.
