Heidenhain: CNC Controls (TNC 620 Series)

Controlling Machine Tools


For milling machines, milling/turning machines and machining centers:

  • Form a complete product line with their various features

  • Control machines with up to 18 axes

  • Their Klartext conversational programming capability is suited for the workshop floor

  • Can also be programmed externally

  • Are also suited for automated production

  • Are the correct choice for everything from simple milling procedures to high-speed milling


The contouring control for lathes:

  • Ideal for both CNC and cycle lathes

  • Enables the familiar manual production of simple workpieces

  • Supports programming with many cycles

  • Its smart.Turn feature offers form- and graphics-supported programming for complicated workpieces

  • Performs complementary milling and drilling operations in a single fixture

  • Also supports vertical lathes

  • Suited for digital or analog drive control


TNC 620 – The Right Control for Milling, Drilling and Boring Machines

The TNC 620 is compact and easy to read. The TNC 620 is a compact but versatile contouring control for up to five controlled axes. Thanks to its flexible operating concept—workshop-oriented programmability with HEIDENHAIN conversational programming or offline programming—and its scope of features, it is especially suited for use on universal milling, drilling and boring machines for the following:

  • Series and single-part production

  • Toolmaking Machine building

  • Research and development

  • Prototypes and pilot plants

  • Repair departments

  • Training and education facilities

And it offers the applicable features both necessary and helpful:

Universal milling machines

  • Free contour programming

  • Milling cycles for complex contours

  • Fast presetting with HEIDENHAIN touch probes


Drilling and boring machines

  • Cycles for drilling, boring and spindle alignment

  • Cycles for linear and circular point patterns


Five-axis machining with swivel head and rotary table

  • When you are programming away from the machine, the TNC 620 automatically takes the machine geometry into account

  • Tilting the working plane

  • Cylindrical surface machining

  • 3-D tool compensation

  • Fast execution through short block processing times
