Crouzet: Miniature Microswitches (V3D - 8326 Series)
Crouzet: Miniature Microswitches (V3D - 8326 Series)

Call for Pricing

Price Quote Form


Order #: V3D-8326


Model Number/Code*:

.
Description Specifications and Drawings


Crouzet: Miniature Microswitches (V3D - 8326 Series)

With over 60 years’ experience in snap-action technology, Crouzet Switches offers a complete range of Microswitches for the highly demanding markets. The extensive choice consists of standard or customized Sub-subminiature, Subminiature, Miniature and Special microswitches, all conform to the most rigorous quality standards.

Our microswitches are characterized by a large range of switching ratings from 1 mA to 25 A, magnetic blowout versions for High DC ratings, sealed models, positive break versions, a wide range of operating temperatures, models for explosive atmospheres, long service life and wide variety of actuators, contact materials and fixing means.

Miniature Microswitches – Standard

  • C-spring snap-action mechanism with wiping contact

  • Broad range of operating forces from 0.25 N to 4

  • Wide choice of connections

  • Housing material complying with IEC 60335-1 for unattended appliances: GWFI 850° C / GWIT 775° C

  • ENEC and cURus approved

  • Choice of pre-assembled actuators on 2 possible fixing positions

  • Case, Button: PET GF (UL 94-V0 / GWFI 960 °C / GWIT 775 °C)

  • Contacts: silver alloy or gold plated (83268/269)

  • Terminals: brass, silver-plated brass (W2, X)

  • Levers: stainless steel, polyamide roller

  • Degree of protection: IP40 (mechanism)

  • Proof tracking index: PTI 250 (PTI 300 on request)

  • Protection against electric shock: button and actuators mounted on position B have reinforced insulation for Ui 250V / Uimp 2,5kV / pollution 2

  • Special levers: special shapes and lengths

  • Lever mounted on position A for higher ratio

  • Special connections: angled, screw with clamp (W5-SP9348), solder with enlarged hole (W2-SP9368), RAST 2.5 (W3R2.5-SP9307)

  • Higher operating force: max 4 N (83261 SP9335, 83262 SP9347)

  • +200 °C versions: max 8A, ENEC and cURus approved (83261-83263-83268-83269 SP9328)

  • 25 A cURus approved version (83262 SP9360)

  • Telescopic plunger and adjustable fixing by threaded barrel: plastic and metal versions (consult us)

Specifications

  • Approx body size (mm): 28x16x10

  • Rating (max): 25A / 250Vac

  • Degree of protection: IP40

  • Operating temperature: -50°C/+200°C

  • Operating force (max): 0.25 –> 4 N

  • Differential travel (max): 0.4 mm

  • Overtravel (min): 1.1 mm

  • Mechanical life (cycles): 1 M


Share your knowledge of this product. Be the first to write a review »
