Description Specifications and Drawings


Crouzet: Subminiature Microswitches (V4D - 8327 Series)

With over 60 years’ experience in snap-action technology, Crouzet Switches offers a complete range of Microswitches for the highly demanding markets. The extensive choice consists of standard or customized Sub-subminiature, Subminiature, Miniature and Special microswitches, all conform to the most rigorous quality standards.

Our microswitches are characterized by a large range of switching ratings from 1 mA to 25 A, magnetic blowout versions for High DC ratings, sealed models, positive break versions, a wide range of operating temperatures, models for explosive atmospheres, long service life and wide variety of actuators, contact materials and fixing means.

Subminiature Microswitches – Standard

  • Flexible leaf snap-action mechanism with wiping contacts

  • ENEC and cURus approved up to +150°C

  • Housing material complying with IEC 60335-1 for unattended appliances: GWFI 850° C / GWIT 775° C

  • Mushroom-head button variant for lateral approach up to 45°

  • Choice of connections with symmetric and asymmetric pinning

  • Choice of pre-assembled actuators

Specifications

  • Approx body size (mm): 20x10x6

  • Rating (max): 12A/250Vac

  • Degree of protection: IP40

  • Operating temperature: -25°C/+150°C

  • Operating force (max): 1,5N

  • Differential travel (max): 0.15 mm

  • Overtravel (min): 0.5 mm

  • Mechanical life (cycles): 0.1 M
