LSIS: PLC (XBM/XBC Series)

Programmable logic controller(PLC) is a general-purpose control device that automatically controls machinery, facilities and assembly lines by user defined programs. It also has a variety of communication functions for sequence, motion and process control.

XGB is the micro PLC that offers maximum automation at minimum cost.
With its high performance and functionality, it can support from simple Control to complex task.

Strengthening its communication functions, XGB offers user-oriented integrated control. Based on its strengths,It can be used in many fields of applications.

Features

XGB, which is a micro PLC that offers maximum automation value at minimum cost, Is capable of handling most tasks from simple to complex control with high performance and functionality. (XEC: IEC Standard Programming)

Compactness & High Performance:

• XGB is more compact but provides powerful functions and performance.

• Compact & Powerful solutions & XGB’s steadfast competitiveness.

Easiness & Convenience
XGB offers convenient user interface with various network diagnosis & monitoring functions and backup function:

• Integrated programming environment

• Enhanced user interface with XG5000/XG-PD

• Various monitoring functions

• Network diagnosis and monitoring

• Optimum communication environment

• Powerful communications: Built-in RS-232C / 485, 2 Expansions for communication

• Network configuration via Ethernet and Cnet I/F

Model No.: XBC-DN10E, XBC-DN14E, XBC-DN20E, XBC-DN20SU, XBC-DN30E, XBC-DN30SU, XBC-DN32H, XBC-DN32H/DC, XBC-DN32U, XBC-DN32UA, XBC-DN32UP, XBC-DN40SU, XBC-DN60SU, XBC-DN64H, XBC-DN64H/DC, XBC-DR10E, XBC-DR14E, XBC-DR20E, XBC-DR20SU, XBC-DR28U, XBC-DR28UA, XBC-DR28UP, XBC-DR30E, XBC-DR30SU, XBC-DR32H, XBC-DR32H/DC, XBC-DR40EB, XBC-DR40EX, XBC-DR40SU, XBC-DR60EB, XBC-DR60EX, XBC-DR60SU, XBC-DR64H, XBC-DR64H/DC, XBM-DN16S, XBM-DN32H, XBM-DN32S, XBM-DR16S
