Specifications and Drawings

RSF Elektronik: Digital Readout (Z 300 Series)

Measurement Readout

For a comfortable issue of measured values RSF Elektronik offers PC interface cards, subdividing electronics as well as the new relaunched digital readout Z 300. Z 300 replaces the legacy model of the Z 7xx series.

The Digital Readout Z 300 is especially suited for use on milling, drilling and boring machines and lathes with up to three axes. A separate I/O unit provides switching inputs/outputs for simple tasks in automation (optional accessory: IFB 48).

Description

The Z 300 display unit is designed as a sturdy upright unit with splash-proof full travel keypad for use in a workshop. It is equipped with a monochrome flat screen for position values, dialog and input displays, graphic functions and graphic positioning support.

Data Interfaces

The Z 300 features an RS-232-C/V.24 serial interface for measured value transfer to a PC or printer, for input/output of parameters and compensation value lists and for dialogs.

Mounting

Z 300 is basically conceived as an upright unit. Mounting possibilities:

Threaded mounting holes M6 and M8 on the housing floor
Mounting frame (optional, ID 532 811-01) for mounting the digital readout in a housing or operating panel

Technical Data:

Features

Axes: 2 or 3
Encoder Inputs: RS-422 inputs for quadrature signals and reference pulse
Display: 5.7 " monochrome flat-panel display for position values, dialogs and inputs, softkeys
Status display: Tool, reference point, operating function, feed rate, ABS/INC, mm/inch, stopwatch

Display Steps
(depends on the signal period of the connected encoder)

Adjustable, max. 7 digits
Linear axes: 1 mm to 0.0001 mm
Angular axes: 1° to 0.001° (00° 00´ 00˝)

Functions

10 datums
16 tools
REF reference mark evaluation for distance-coded or single reference marks
Distance-to-go mode
Scaling factor
mm/Inch switching
Absolute/incremental display
On-screen help and operating instructions
Graphic positioning support ("near zero" warning)
Calculator

Mode: Milling/Drilling/Boring

Calculation of positions for hole patterns (circular patterns as well as linear patterns)
Tool radius and tool length compensation
Probing functions for reference-point acquisition with KT edge finder:
"edge", "centerline", "circle center"
Linear hole patterns, bolt hole circles

Mode: Turning
