MEAN WELL: DC/DC DIN RAIL SUPPLY 12V 401W(DDR-480B-12)

DDR-480B-12 DC-DC Ultra slim Industrial DIN rail converter; Input 16.8-33.6Vdc; Single Output 12Vdc at 33.4A; DC OK and remote ON/OFF.

Price : $234.33

Quantity in Stock:55

Availability: Usually Ships in 3 to 5 Business Days
Order #: DDR-480B-12

Qty:

Description

Ordering Information

Specifications and Drawings

DC/DC DIN RAIL SUPPLY 12V 401W(DDR-480B-12)
DDR-480 series is a 480W DIN Rail type DC-DC converter with main features including DIN rail-type easy installation, ultra slim width (85.5mm), 2:1 wide input voltage, fanless design, -40~+80°C wide operating temperature, 4KVdc I/O isolation, 150% peak load, current sharing, DC OK, adjustable output voltage and full protective functions.

Features:

Compliance to EN50155 and EN45545-2 railway standard

Width only 85.5mm

2:1 wide input range

-40~+80°C wide operating temperature

150% peak load capability

Current sharing up to 1920W(3+1)

DC output adjustable

Cooling by free air convection

Can be installed on DIN rail TS-35/7.5 or 15

Protections: Short circuit/ Overload, Over voltage/ Over temperature/ Input reverse polarity/ Input under voltage protection

4KVdc I/O isolation (Reinforced isolation)
