DIN Rail Security Power Supply DRS-240-12
MEAN WELL DRS-240, and DRS-480 AC/DC DIN Rail-Type Security Power Supplies are 240W and 480W all-in-one intelligent security power supplies. In addition to the primary output, the MEAN WELL DRS-240 and DRS-480 AC/DC DIN Rail-Type Security Power Supplies feature an additional charger circuit that automatically adjusts the charge current depending on the primary output current. DRS-240 and DRS-480 accept a universal 90VAC and 305VAC input voltage. DRS-240 supports output 12VDC, 24VDC, 36VDC, and 48VDC nominal systems, while DRS-480 supports 24VDC, 36VDC, and 48VDC. With high efficiency of up to 93.5% (DRS-480) or 92% (DRS-240), these power supplies can operate with free air convection cooling under -30°C through +70°C ambient temperature. Key protection features include overload, over-voltage, battery low voltage disconnect, and battery reverse polarity protection. DRS-240 and DRS-480 also provide Form-C contacts and LED indicator alarm signals for AC-fail, battery low, charger circuit fail, and DC-OK to allow easy integration into security systems that comply with local alarm codes.
Applications:
Public safety battery back-up (red box)
Security systems
Emergency lighting systems
Alarm systems
Uninterruptible DC-UPS systems, battery detection systems
Central monitoring systems
Industrial automation
