MITSUBISHI: PLC Controller PLC main unit: FX3UC-32MT-D

The MELSEC-F Series PLC provides a compact control solution with flexible options for system configuration.

Power supply, CPU, and I/O are all included in a single unit, providing basic functionality that can then be supplemented with a wide variety of expansion options for I/O, analog, positioning, and communications.

The FX3UC is the new ultra-compact high-speed, fully expandable PLC. Based on 24V DC power and using connector-type transistor I/O, the FX3UC is designed for Space-conscious and modular applications. Created in line with the FX3U series, the FX3UC incorporates such attributes as built-in high-speed I/O and the dual system-bus architecture, optimizing communication, networking, analog, and positioning control.

• 3rd generation super-compact PLC
• Reduced size and wiring using connector-type I/O
• Built-in high-speed processing and positioning
• Even with its ultra-compact size, the FX3UC can be expanded to locally control up to 256 I/O, and up to 384 points with CC-Link remote I/O.
• Product Details

Ultra-compact size main unit including many upgraded features from the FX2N, including high expandability using Special Adapters to add functionality.

• Fast Instruction Times

Basic Instructions: 0.065 μs / instruction (Contact Instruction)

Applied Instructions: 0.642 μs / instruction (MOV Instruction)

• Large Memory

64,000 steps of built-in program memory.

Flash Memory Cassettes with loader function are available.

• Applicable Standards

All products support EN and UL/cUL standards.

Various shipping approvals are supported as well.

• Large Device Memory
