INDUCTIVE PROXIMITY SENSOR 4MM CYLINDRICAL IME2S12-04N4DC0

Cylindrical inductive safety switch for position monitoring

The inductive safety switches of the IME2S product family are used for safe position and area monitoring. Thanks to the very compact design and wide range of connection variants, they offer optimum integration into the machine design. The IME2S switches work without making contact and are low-wear. The inductive safety switches do not require a separate actuator to do their monitoring tasks. On the contrary, they are generally activated by metals, for example on machines. Due to the large response range, the safety switches allow for assembly tolerances, simplifying mounting and adjustment. The IME2S can be connected to a safe control solution via its self-monitoring switching outputs (OSSDs), allowing for high safety with PL d (EN ISO 13849).

Benefits

High machine availability thanks to low susceptibility to dirt and moisture

Long product service life due to low-wear and low-maintenance workings

Easy integration: Sensors can be mounted to save space thanks to their compact design and do not need a separate actuator

Fast diagnostics via LED status indicator

High reliability and precise switching behavior due to proven ASIC technology

Safe, direct connection to a safe control solution by means of OSSDs

Easy and flexible connection options thanks to variants with male connector, cable or cable with male connector

Features

Types: M12 to M30

Increased response ranges: 4 mm to 15 mm

Two OSSD safety outputs

Enclosure rating: IP67

Temperature range: –25 °C to +70 °C

Nickel-plated brass housing, plastic sensing face

Up to performance level PL d (EN ISO 13849)

Connection variants: M12 male connector, cable or cable with M12 male connector
