MULTITASK PHOTOELECTRIC SENSOR WTT12LC-B2563

The new home of sensing range

PowerProx MultiTask photoelectric sensors combine powerful time-of-flight technology with compact sensor housings, giving machine designers maximum flexibility. They reliably detect objects that are traveling at high speed, small and flat objects, and jet-black or shiny objects at sensing ranges between 5 cm and 4 m, including at large detection angles. The WTT2SL, WTT4SL, WTT12L, WTT190L and WTT280L variants of the photoelectric sensors are designed to meet different requirements and provide the ideal solution to overcome any challenge.

Benefits

Reliable object detection over long sensing ranges and at large detection angles

Precise, simple adjustment using a potentiometer, teach-in button or display

Excellent functionality with IO-Link

The rugged VISTAL® sensor housing ensures high availability and a long service life

Suitable for a wide range of applications: the variants of the photoelectric sensors are designed to cover a variety of detection requirements

Compact sensors allow for significant flexibility in machine design

Features

Time-of-flight technology

Laser class 1, red and infrared light

Sensing range: 5 cm to 4 m

Very small background range: 6 mm

Switching frequencies of up to 1,000 Hz

The option of up to three adjustable digital outputs or one IO-Link analog output: for up to eight switching points, distance value and smart sensor functionality
