Features:

• High accuracy (Smooth operation)

• Energy-saving (High efficiency)

Power loss has been reduced by up to approximately 30% and efficiency has been increased by 10% compared with our conventional DC servo motors. This reduces heat generation within equipment and contributes to energy savings.

• Low noise

Brush vibrations have been reduced, and the rigidity of motor parts has been improved. Compared with our conventional DC servo motors,* noise levels have been reduced by up to 8 dB.

• Low-voltage models available

In addition to 75 VDC class models, low-voltage (24 VDC class) models are also available. The low-voltage models are safe for use in medical equipment and other applications close to people.

• IP43 protection rating

All servo motors have a protection rating of IP43.

Specifications:

• Flange size : 88 mm sq.
• Rated Output Power: 400 - 500 W
• Rated armature voltage: 80 - 85 VDC
• Rated Torque：1.53 – 1.91 Nm
• Continuous stall torque: 1.7 - 2.16 Nm
• Peak Stall Torque: 12 – 16.7 Nm
• Rated speed: 2500 RPM
• Maximum speed: 3000 - 4000 RPM
• Tachogenerator : Optional
• Brake: 90VDC(Standard), 24VDC, 48VDC(Options)
• Encoder :Line drive : Standard: 2000 P/R, Optional: 200, 500, 1000 P/R, Open collector: Optional: 200， 500， 1000， 2000 P/R
