SIMATIC DP, Electronics module for ET 200SP (6ES7136-6DB00-0CA0)
Siemens 6ES7136-6DB00-0CA0 is SIMATIC DP, Electronics module. SIMATIC DP, Electronics module for ET 200SP, F-DQ 4X24 V DC/2A, 15 mm width, up to PL E (ISO 13849) up to SIL 3 (IEC 61508).

SEND/RECEIVE with and without RFC1006 multicast, PROFINET IO controller, DHCP, SNMP V2, web, diagnostics, initialization via LAN, access protection via IP access list integrated real-time switch ERTEC 400, 2xRJ45 connection for LAN with 10/100 Mbit/s.

Fail-safe / Safety DC digital output module - cabinet I/O - High-feature version - Siemens (SIMATIC ET 200SP) - F-DQ 4x 24 V DC/2 A PM HF - PLe SIL3 - LED indicator - 4I/Os [4DO (4 x digital outputs (24Vdc 2A / 12-2000O / 30Hz resistive load))] - Supply voltage 24Vdc - Plug-in mounting - CC01 colour - Rated for 0...+60°C ambient

The 6ES71366DB000CA0 is output module with dimensions: 15 mm width x 73 mm height x 58 mm depth. Operating temperature range is from 0°C to 60°C.
