SIMATIC S7-1200, CPU 1214C, compact CPU (6ES7214-1BG40-0XB0)
The S7-1200 controller provides the flexibility and power to control a wide variety of devices in support of your automation needs. The compact structure, flexible configuration, and powerful instruction set combine to make the S7-1200 a perfect solution for controlling a wide variety of applications.

The CPU combines the following elements and more in a compact housing to create a powerful controller:

● A microprocessor

● An integrated power supply

● Input and output circuits

● Built-in PROFINET

● High-speed motion control I/O

After you download your program, the CPU contains the logic required to monitor and control the devices in your application. The CPU monitors the inputs and changes the outputs according to the logic of your user program, which can include Boolean logic, counting, timing, complex math operations, motion control, and communications with other intelligent devices.

The CPU provides a PROFINET port for communication over a PROFINET network. Additional modules are available for communicating over networks and protocols such as the following:

● PROFIBUS

● GPRS

● LTE

● WAN with Security Integrated Features (Firewall, VPN)

● RS485

● RS232

● RS422

● IEC 60870

● DNP3

● USS

● MODBUS
