CNC Systems for Milling Machine - CNC 8060elite M

Fagor CNC systems are prepared for the complete digitalization of the machines
On which they are installed. Fagor CNCs include the most advanced technologies,
Features, and protocols that facilitate interoperability with other production plants' Systems.

Designed for high speed machining centers and precision mold making in industries such as automotive or aerospace offering the latest technology.

The ideal CNC for machining centres for the manufacture of precision moulds for industries like automotive or aerospace production parts for industries like the oil or the energy.

All advances to make the job easier and simple: touch screen. High-definition graphics. More than 500 Mb of memory of all CNC, expandable by Compact Flash series. Simulator on PC free. Pop-up (exclusive Fagor) navigation system. and all this combined with all the advantages that the CNCelite.

01. Complete redesign
More powerful control algorithms and circuits with the latest technology

02. Ethernet
New Sercos III Servo Bus, with Industrial Ethernet technology at 100 MBd.
Better integration of functions that depend on more than one axis

03. Full Digital
Feedback inputs prepared for FeeDat, SSI, etc. real-time serial communication protocols.
Nanometer resolution.

04. Smaller
We have created an extremely compact CNC platform with reductions of around 45% to 60% (depending on model) in size compared to the previous CNC platform.

05. Wide range of monitors and keyboards configurations
Provides maximum flexibility when designing the machine control panels

06. VESA mount
New installation system. When using the simple VESA mount adapter, a CNC can be connected directly to monitors of various sizes.

07. Web technology-based HMIelite
Easy programming and portability to other platforms.

08. Always ready for the future
QUERCUS is the CNC automation system that can help you grow vertically and allows you to be always prepared for most demanding requirements of the current and future markets.
