Fagor CNC Systems for Cutting - CNC 8070elite L
Fagor CNC systems are prepared for the complete digitalization of the machines On which they are installed. Fagor CNCs include the most advanced technologies, Features, and protocols that facilitate interoperability with other production plants' Systems.

Solution based on the 8070elite-L CNC and the Quercus drive system, providing the best performance, high precision and interpolation of 5 or more axes for the most demanding solutions
Waterjet 3D, laser 2D/3D Cutting, Laser for tubes, Laser blanking
Fagor Dynamic Override algorithm allows “on the fly” changes to acceleration and jerk control, allowing you to change/improve part finish (smoothness) during the cutting process.
Any type of tube structure and shapes can be cut including round, square, rectangle, etc. as well as angled and spiral tubes.
Flexibility in the contour design provided by CNC programming. Fagor CNC can control multiple and independent heads (more than one cutting process at the same time).
High-speed cutting
HSSA II (High Speed Surface Accuracy) for laser cutting machines.
EtherCat connectivity & analogue I/IOs
Proportional valves
Laser generator
Laser head
Cutting specific HMI
Specially designed HMI for cutting with 3D graphic
Technological tables for different material, piercing and cutting
Fully customizable virtual keyboard and OP to the preferences of each OEM
Specific functions to maximize the performance of each cutting solution
3D GAP Control
PWM
Power Control
Synchronized switching / Fly Cutting
Leap Frog
